Slimline Mini-Clad

Capacity: 400kg

Improving on one of our most popular cladding machines the Mini-Clad has been upgraded to the new Slimline version and the result is an even more compact profile, yet still retaining its position as the industry’s most powerful ‘configuration free’ cladding lifters.

Lighter and slimmer with the ability to lift up to 400kg, operators are able to complete fuss-free lifting thanks to the quad-pad suction frame. The dual-circuit vacuum system provides safe lifting of vertical wall panels up to 18m long, horizontal panels up to 8m long, and roof panels up to 5m long (depending on thickness).

The Slimline Mini-Clad comes complete with a manual 90° tilt and 90° left & right rotation for effortless installation, it is also compatible with GGR’s range of mini spider cranes, mini crawler cranes, and trailers cranes.

If you are looking to hire or purchase a cladding lifter, or require any further information, contact GGR Group today.

  • 400kg capacity
  • Dual circuit vacuum system with vacuum gauge, reserve tank and non-return valve for each circuit
  • On-board control panels (including suction release).
  • Optional radio / cable remote control available (for purchase machines only, not currently available in hire fleet)
  • 90° tilt
  • 90° rotation left & right
  • 110/240v intelligent charger system
  • Audio-visual low vacuum alert
  • Integral control panel and suction release
  • Securing straps supplied as standard
  • Suitable for flat smooth, MR & MMR panels ONLY
  • Not suitable for use in the rain – read more in our safety guide
  • Maximum wind speed for safe use is 29km/h, 18mph, 16.5 knots or 8 m/s
  • Ref: VCL11
