GK20 – Pick & Carry Crane

Capacity: 2.0t x 0.45m

A new member of our pick and carry crane range, the GK20 is the ultimate machine for lifting and carrying loads over rough terrain. This compact crawler crane features an extendable tracked undercarriage for stable transportation of loads over uneven ground.

The tracks can also be closed and tucked away in the undercarriage so the crane can easily travel into a tight working space. Delivering the optimum combination of compactness and lifting power, this crawler crane is only 820mm wide and can fit through a standard door frame, yet provides 2 tonnes of lifting capacity without the need for outriggers—ideal for lifting in restricted spaces.

Powered by 80V battery, the GK20 pedestrian-operated crane comes with a radio remote control and digital safe load indicator as standard. A new Searcher Hook is now available for the G20 and GK20 crane which gives customers that little extra reach.

If you are looking to hire or purchase a G20 Pick & Carry Crane or require any further information, contact GGR Group today.

  • Maximum safe working load (tracks closed) 2 tonnes x 0.45m
  • Maximum safe working load (tracks open) 1.5 tonnes x 0.45m
  • Max working radius 3.45m
  • Max lifting height 5.3m
  • Width: 820mm (tracks closed), 1220mm (tracks open)
  • Length: 2250mm
  • Height: 1750mm
  • Weight: 2300kg
  • Telescopic box boom, 2 section hydraulics, 1 section manual
  • Rubber tracks
  • Powered by 80v rechargeable battery
  • 2 motors on undercarriage with counter-rotation controlled by AC electronic controller
  • Electromagnetic brakes on motors
  • Travel speed 2km/h
  • Standard: Radio remote control, digital safe load indicator, reversing alarm, emergency stop button, overload alarm and lamps
  • Optional: searcher hook, jib, full winch system
  • Ref: MCGK20
